PREMIUM IN-CAB EXPERIENCE
Industry-leading utility SxS, with a premium RANGER Pro Shield™ Cab that keeps dust out 3x better than its closest competitor with factory-installed Heating and A.C.
ENGINE & DRIVETRAIN
| Engine Type |
4-Stroke Twin Cylinder DOHC |
| Cylinders-Displacement (cc) |
999 cc / 82 HP |
| Fuel System |
Electronic Fuel Injection |
| Transmission/Final Drive |
Automatic PVT H/L/N/R/P; Shaft |
| Drive System Type |
High Performance On-Demand True AWD/2WD/VersaTrac Turf Mode - Active Descent Control (ADC) |
| Cooling |
Liquid |
Suspension
| Front Suspension |
Dual A-Arm 27.9 cm Travel |
| Rear Suspension |
Dual A-Arm 27.9 cm Travel |
Brakes
| Front/Rear Brakes |
4-Wheel Hydraulic Disc With Dual-Bore Front Calipers |
| Parking Brake |
Park In-Transmission |
| Front Tyres |
27 x 9-12; Maxxis MU511 |
| Rear Tyres |
27 x 11-12; Maxxis MU521 |
| Wheels |
Aluminium Black Xcelerator 2.0 |
DIMENSIONS
| Bed Box Dimensions (L x W x H) |
93.3 x 137.8 x 31.75 cm |
| Front/Rear Rack or Box Capacity |
N/A kg / 454 kg |
| Fuel Capacity |
43.5 L |
| Ground Clearance |
33 cm |
| Overall Vehicle Size (L x W x H) |
305 x 165 x 198 cm |
| Wheelbase |
206 cm |
| Estimated Dry Weight |
850 kg |
Features
| Cargo System |
Lock & Ride® |
| Hitch Towing Rating |
1133.9 kg |
| Hitch/Type |
Standard 5 cm Receiver |
| Instrumentation |
Dual-sweep Analog Dials with 4 in LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Volt Meter, Service Indicator and Codes, Seat Belt Reminder, DC Outlet |
| Variants |
Off-road |
